Large size refined appearance.

Both control and entertainment functions.

Built-in Intelligent
Gateway

The device has a built-in Tuya ZigBee gateway, which can easily view and control the device through the mobile APP, support remote control, and meet the all-round needs of users for smart home.

Supports Multiple
Playback Modes

Double Up On Multiple Experiences: Meet the music playback of two rooms at the same time, and can separately control the playback volume of each room. This means that one device can provide music services to two rooms at the same time, and each room can adjust the volume independently as needed, satisfying the user’s need to enjoy the same music in different Spaces.

The device also uses two digital power amplifier chips to bring every sound detail to life, providing an immersive sound experience. This advanced chip technology can ensure that the sound performance of music is more realistic and clear, so that users can feel the charm of music more immersive.

Ultra-thin Aluminum Body

The combination of the one-piece molding process and CNC diamond cutting technology creates an ultra-modern minimalist, ultra-thin metal body.
The delicate treatment of the sandblasting process makes the surface of the fuselage show a unique luster and texture.
This design style and manufacturing techniques make the device a highly attractive modern product.

Alarm function

The built-in power amplifier can be connected with various alarm devices, such as security alarms (smoke, carbon dioxide, human body), door and window sensors, infrared sensors, surveillance cameras and so on. When special circumstances occur, the built-in power amplifier will issue a clear and loud alarm reminder sound to ensure that you can know and take appropriate measures in time.

Installationin structions

① Background music host
② Metal hook
③ Bottom box

Pre-bury the bottom box in the UP direction as indicated inside the bottom box. Securely install the two metal hooks, paying attention to the direction of the metal hooks.

Connect the wiring diagram as needed
(Interface names are labeled on the back cover of the host).

After connecting the wires, tilt the host at a 45-degree angle, securing the metal pendant from above by snapping it down from the top. Finally, secure the bottom two corners.

Install the provided screws on the top of the host, and the installation is complete.

Complete
Machine
Wiring
Definitions

Do not connect high-voltage power to the 485 interface

Product Parameter

Dimensions :182mm*127mm*7.8mm
Installation size :175mm*102mm*62mm
Display :1024*600 HD IPS LCD
CPU: Cortex-A7 quad-core 8G
Network: Wireless 802.11b/g/n, 10/100M Ethernet
Interface: R45, RS485, I/0, audio output Audioout, external audio input Aux-in

The Craft Aesthetics Of The Ultra-Thin Body Combine Perfectly With The Practicality Of Modern Versatility

Built-in Intelligent Gateway

Built-in intelligent gateway The device has a built-in Tuya ZigBee gateway, which can easily view and control the device through the mobile APP, support remote control, and meet the all-round needs of users for smart home. The device also supports group management control and supports single gateway/multi-gateway import devices, making it easier for users to manage and control smart home devices.

Ultra Thin

The combination of the one-piece molding process and CNC diamond cutting technology creates an ultra-modern minimalist, ultra-thin metal body. The delicate treatment of the sandblasting process makes the surface of the fuselage show a unique luster and texture, highlighting the ultimate process and design concept. This innovative design style and superb manufacturing techniques make the device a highly attractive modern product.

Alarm function

在这里添加您的标题文本

The built-in power amplifier can be connected with various alarm devices, such as security alarms (smoke, carbon dioxide, human body), door and window sensors, infrared sensors, surveillance cameras and so on. When special circumstances occur, the built-in power amplifier will issue a clear and loud alarm reminder sound to ensure that you can know and take appropriate measures in time.

Installationin structions

Complete Machine
Wiring Definitions

Do not connect high-voltage
power to the 485 interface

Product
Parameter

Dimensions :182mm*127mm*7.8mm
Installation size :175mm*102mm*62mm
Display :1024*600 HD IPS LCD
CPU: Cortex-A7 quad-core 8G
Network: Wireless 802.11b/g/n, 10/100M Ethernet
Interface: R45, RS485, I/0, audio output Audioout, external
audio input Aux-in
